Lorex Pro Series 4K 32 Camera Capable 8TB Wired NVR System with 8MP (4K) A10 IP Dome Cameras

NC4K8-3216BD-E851Lorex for business badge
Number of cameras:
Color:
Purchase at pro.lorex.com
Lorex Partner Program Exclusive: Pricing available to Lorex Business Partners
bi-shield

Safe & Secure

Apps are protected with end-to-end data encryption.

bi-returns

Risk Free

Return for any reason within 30 days of delivery.

bi secure payment

Flex Payments

Spread out payments with easy financing options.

No Monthly Fees

Local recording protects privacy and saves money.

Features

Resolution

Color Night
Vision

IK10
Vandal Proof

IP67
Weatherproof

Built-in
Microphone

Person and Vehicle
Detection

8TB Secured Local Storage



Capture the details you need

4K recording resolution can make all the difference when it comes to capturing those important moments. This camera features an 8MP image sensor, which provides an exceptionally high level of detail and clarity. 4K quality also improves post-recording digital zooms to help decipher distant details, as the higher amount of pixels will keep the quality of the image for longer as the digital zoom is applied.



Don’t lose any details at night

See in color all night long thanks to this camera’s Color Night Vision (CNV) technology. CNV works best with plenty of ambient lighting, but not to worry, in total darkness, this camera will automatically revert to its powerful infrared LEDs for crisp black and white footage.



Smart Motion Detection (Person and Vehicle)

This camera comes with advanced person and vehicle detection that helps identify more important objects that enter the camera's field of view. Thanks to this innovative feature, you will only get a push notification whenever motion from a person or vehicle is detected on your property. This effectively reduces the number of unwanted false alerts.





Local Storage - No Monthly Fees

  • 2 hard drive bays with up to 2 × 16TB of storage space

  • Security grade hard drive designed for advanced processing and the workload of 24/7 recording

  • Storage mirroring for continuous back-up of data from one hard drive to another




Plug-and-play PoE Installation

Connect IP cameras to the integrated Power-over-Ethernet (PoE) ports for a truly plug-and-play surveillance experience. Thanks to PoE technology, each camera only requires a single ethernet cable to connect it to the NVR.



What's Included?

ACC front

Package Contents:

1 × PoE Switch

1 × Power Cord

2 × Rack Mount Bracket

8 × Mounting Screws

1 × SFP Dust Cap

4 × Rubber Feet

Quick Start Guide


  • Centralized power distribution - Easy all-in-one PoE switch
  • 1 Gigabit rated RJ45/SFP port for fast device/network connection
  • High speed transmission of IP surveillance data
  • 220W total PoE power budget (up to 30.8W per port)
  • Convenient Real-time PoE usage LED indicators
N884 Front Overview
  1. Power, Hard Drive & Network Statuses
  2. Channel Statuses
  3. Navigation Controls
  4. Power Button
  5. Playback Controls
  6. Switch Keyboards (shift)
  7. Start/Stop Recording (rec)
  8. Special Functions (fn)
  9. Back/Cancel (esc)
  10. Info Button
  11. USB Port
N884 Back Overview
  1. Power Connection
  2. Power Switch
  3. Camera Connection (PoE)
  4. RS485 Alarm
  5. Monitor Connection (VGA)
  6. RS232
  7. Audio In/Out
  8. Monitor Connection (HDMI)
  9. USB Port
  10. Network Connection (LAN)


Package Contents:

This 32-channel NVR has 16 ports. The other 16 channels can be utilized by adding a PoE switch (sold separately).

4K NVR

Ethernet Cable

USB Mouse

HDMI Cable

Power Cord

2 × 6-Pin Cable Adapter

E851AD Overview
  1. Dome Cover
  2. Dome Cover Screw (x3)
  3. Lens
  4. IR (Infrared) Light (x3)
  5. Cable Notch
  6. Camera Base
  7. Microphone*
  8. Reset Button
  9. MicroSD Card Slot**


Package Contents:

4K Vandal Proof Dome Camera

Allen Key

Mounting Kit

Ethernet Extension Cable

*Audio recording and listen-in audio are disabled by default. Audio recording and/or use of listen-in audio without consent is illegal in certain jurisdictions. Lorex Corporation assumes no liability for use of its products that does not conform with local laws.
**A microSD card can be inserted for independent recording. Data can be accessed through the camera using a web browser but will not upload to the NVR or to the cloud for mobile app viewing

Product Support

ACCLPS263B - 16-Channel PoE+ Switch

N884 Series - Lorex 4K Pro Series Network Video Recorder

E851AD Series - 4K IP Wired Dome Security Camera
